Cjm250 Mini Bench Lathe Metal Hobby Lathe Household Small Desktop Lathe Lower Price with Auto Feeding

Basic Info

Model NO.	CJM250
After-sales Service	1 Year
Warranty	1 Year
Type	Horizontal Lathe
Guide Rail	Horizontal Guide Rail
Power Source	Electric
Controlling Mode	Artificial
Automatic Grade	Manual
Setting Mode	Table
Precision	Precision
Certification	CE
Condition	New
Transport Package	Full Closed Plywood Box
Trademark	SENMO
Origin	China
HS Code	84589900

Product Description

Bench Lathe CJM250 Feature

·Most economical, widely useful hobby lathe. Power longitudinal feed allows threading

·V-way adopts double triangle and rectangle slideway. Induction hardened and ground bedway

·Spindle is supported by precision tapered roller bearing. Geared headstock enables to change speeds quickly

·Large MT4 spindle bore. Precise cuts with cross & longitudinal power feed

Specifications	CJM250
Swing over bed	250mm
Swing over cross slide	100mm
Distance between centers	500mm
Spindle bore	26mm
Spindle taper	MT4
Number of spindle speeds	12
Range of spindle speeds	80-1600rpm
Carriage travel	130mm
Tool post travel	60mm
Number of metric threads	15
Range of metric threads	0.25-2.5mm
Number of imperial threads	9
Range of imperial threads	12-96 T.P.I
Longitudinal feed	0.03-0.375mm/r
Cross feed	0.015-0.188mm/r
Tailstock quill travel	55mm
Tailstock taper	MT3
Main motor	750W
N.W./G.W.	163/180kg
Packing size	1200x620x600mm

Standard Accessories	Optional Accessories
·3-jaw chuck (125mm)	·4-jaw chuck (160mm)
·V-belt (O) 630	·Back plate
·Dead center	·Follow rest
·Tool wrench	·Steady rest
·Allen key	·Face plate (160mm)
·Open end wrench	·Live center
·Splash guard	·Turning tool set
	·Oil tray
	·Threading dial
	·Stand
