Mini Bench Lathe Metal Hobby Lathe Household Small Lathe Small Desktop Lathe Lower Price C210
Our ServicesWhat we can do for you? 1. Experienced staffs answer all your questions in time. 2. Customized design is ava
Basic Info
Model NO. | C210 |
Controlling Mode | Artificial |
Automatic Grade | Manual |
Setting Mode | Table |
Precision | Precision |
Certification | CE |
Condition | New |
Transport Package | Full Closed Plywood Box |
Trademark | SENMO |
Origin | China |
HS Code | 84589900 |
Product Description
Bench Lathe Feature |
·Precision ground and supersonic frequency hardened bed ways |
·It features with high accuracy and well wear-resisting |
·Spindle is supported by precision tapered bearing |
·Safety magnetic switch or lock key switch |
Specifications | C210 |
Swing over bed | 210mm |
Swing over cross slide | 110mm |
Distance between centers | 320mm |
Bed width | 135mm |
Spindle bore | 20mm |
Taper of spindle bore | MT3 |
Spindle speed | 125-2000rpm |
Taper of tailstock | MT2 |
Metric threads range | 0.4-3.0mm |
Inch threads range | 10-44TPI |
Longitudinal feed | 0.1-0.2mm/rev |
Max. cross slide travel | 110mm |
Max. top slide travel | 70mm |
Max. tailstock quill travel | 65mm |
Motor | 550W |
Net weight | 105kg |
Packing size(LxWxH) | 94x56x55cm |
Standard Accessories | Optional Accessories |
·3 jaw chuck | ·4 jaw chuck |
·Change gears set | ·Follow rest |
·Dead center | ·Steady rest |
·Toolbox & tools | ·Face plate |
·Live center | |
·Oil tray | |
·Drill chuck |
